DAC Centrifugal Compressor
882.75-105930 [cfm]; 25-3000 [m3/min]
0.6-50 [bar]; 8.7-725.2 [psig]
132-14500 [kW]; 175-20000 [hp]
DENAIR DAC Centrifugal Compressor
DownloadFor more information about certifications, please contact us.>
- Certified Class Zero Oil-free Air
- Less Energy Consumption
- High Reliability
- Easy Maintenance
- Smart Operation System
Performance advantages of DAC Centrifugal Compressor:
-
Certified Class Zero Oil-free Air
The centrifugal compressors were granted certificates of conformity with compressed air purity class for total oil 0, tested according to ISO 8573-1, which prevents oil from polluting your process system.
-
Less Energy Consumption
Efficient impeller and stage design for excellent specific energy requirement (SER). It helps lower your electric bills significantly and has a positive impact on the environment.
-
High Reliability
Anti-surge control system avoids costly damage to the machine and production loss due to process interruption. Variable speed drive solution reduces the sudden current demand during the starting process of the centrifugal compressors. This avoids the voltage dips and other undesirable effects, especially when your power supply is limited.
-
Easy Maintenance
Customized coolers are suitable for various working conditions and they are easy for cleaning and maintenance.
-
Smart Operation System
Three operating modes can be realized by the control system: full constant pressure mode, automatic dual mode and self-balancing mode. It can intelligently adjust according to the actual operation conditions and gas demand to ensure that the equipment is always in a state of high efficiency, energy saving and stable operation.
-
Impeller
The aerodynamic design of Denair centrifugal compressors applies advanced aerodynamic principles, combined with self-developed high-efficiency modeling software, CFD simulation and other means, to ensure optimal inter-stage compression ratio distribution and stable reliability; The long-term product verification design experience, rich impeller database and design software of Denair team ensure the superiority of aerodynamic design.
-
Rotor Dynamic Design
Professionally designed rotors and bearings ensure that they can operate under reasonable oil film temperature, pressure and thickness, effectively reducing bearing power consumption. Through extracting the stiffness and damping data from a large number of bearings, DENAIR conduct rotor dynamics analysis to ensure reasonable vibration value of the rotor as well as ensuring the rated speed setting is far away from the critical speed and enhancing the stability of the whole machine.
-
High Performance IGV
The electric actuator drives the airfoil stainless steel blades, precisely controls the opening of the inlet guide vanes, changes the pre-swirl value of the intake air, and improves the operating efficiency of the centrifugal compressor. When the compressed air demand is reduced, the IGV can save up to about 9% energy consumption, making the centrifugal compressor run efficiently and energy-saving.
-
Control Cabinet
The highly integrated control cabinet adopts Siemens PLC with touch display screen, which is concise and clear and easy-to-operate. Our controller supports multi-languages switching and all parameters read and displayed in real time, especially key information like running curves and numbers. Meanwhile, automatic alarm, chain shutdown protection, anti-surge and surge prediction fuctions are available to ensure the sagety and reliability of equipment operation.
-
Integrated Casting Gearbox
Adopting modular design, the horizontally split gearbox is integrally cast with volutes at all stages while the cooler box is integrally cast design. Compared with the splitted and welded gearbox, compression unit of horizontal one is with higher strength mechanism, fewer processing surfaces, more reliable operation and there is no assembly error, no deformation, low noise and low vibration between the volute and the gear box at all stages. Compared with integral casting, processing, assembly, transportation, on-site installation and maintenance f or our coolers are simpler. When compression unit needs to be returned to the factory for overhaul, the integral casting requires larger lifting equipment and destroys the installation foundation, resulting in secondary installation but ours, which is modular design, perfectly solve this problem.
-
High Reliability Bearing
Through the professional design of rotor dynamics, the tilting pad bearing with high load capacity and low vibration is adopted. The bearing bush can be automatically adjusted according to the load and temperature changes, so as to ensure the stable operation of the unit under various harsh working conditions.
-
